Hadley Check Valve

Hadley check valve, or non-return valve. Specifically designed for Hadley air sets. Angled valve with a 7/16" male thread for the air reservoir and a 1/4" hose clamp fitting for the compressor supply.

Default delivery time

: 2-4 Work days

€ 12,50

Price per unit

Quantity:

Order

Description
Information
Attachments

Hadley Check Valve

Check valve for Hadley air sets. Also called a non-return valve, check valve, or backflow preventer.
This right-angle check valve has a 7/16 male thread for connection to the reservoir. A 1/4-inch hose must be used for the supply from the compressor.

A check valve is used to allow air to flow into the reservoir (tank). However, the valve closes in the opposite direction. This means that air can flow in, but cannot flow back out.

Shape

Check Valve

Thread (A)

1/8 NPT (M)

Tube size

1/4 inch

Tube connection

Compression fitting

Material

Brass

Max pressure

10 bar

Made in

United States

HAD15249-Hadley-Terugslagventiel.pdf
